Application:
· Industrial use such as welding, glass cutting;
· Fish farming, aquaculture;
· Oxygen supply for ozone generator;
· Oxygen cylinder filling system.
Techniacl specifications:
| Flow Rate |
0-15LPM / 0-20LPM / 0-30LPM / 0-40LPM / 0-60LPM |
| Purity |
93% (±3%) |
| Outlet Pressure |
0.04-0.07MPA (6-10PSI) |
| Sound Level |
≤60db / ≤60db / ≤60db / ≤60db / ≤60db |
| Power Consumption |
≤850W / ≤1100W / ≤1650W / ≤2200W / ≤3300W |
| LCD Display |
Switch time, operating pressure, present working time, accumulated working time |
| Net Weight |
90Kgs / 95Kgs / 140Kgs / 160Kgs / 245Kgs |
| Alarm |
Low purity alarm, High&Low perssure alarm, Power failure alarm |
| Dimension |
680*500*1580mm / 680*500*1580mm / 860*630*1580mm / 860*630*1580mm / 860*630*2120mm |
